| TYPE | DESCRIPTION |
| Mfr | Molex |
| Series | Micro-Fit 3.0 43045 |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Features | Solder Retention |
| Connector Type | Header |
| Voltage Rating | 600V |
| Current Rating (Amps) | 8A |
| Mounting Type | Surface Mount |
| Number of Positions | 12 |
| Number of Rows | 2 |
| Style | Board to Cable/Wire |
| Operating Temperature | -40°C ~ 105°C |
| Applications | Automotive, General Purpose, Industrial, Medical, Telecommunications |
| Contact Type | Male Pin |
| Fastening Type | Locking Ramp |
| Number of Positions Loaded | All |
| Termination | Solder |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Brass |
| Insulation Color | Black |
| Pitch - Mating | 0.118" (3.00mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 15.0µin (0.38µm) |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Post | 100.0µin (2.54µm) |
| Contact Shape | Square |
| Insulation Height | 0.390" (9.91mm) |
| Shrouding | Shrouded - 4 Wall |
| Insulation Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Row Spacing - Mating | 0.118" (3.00mm) |
